ECHOMAP™ UHD2 5" cv Chartplotters 54cv without Transducer; includes Garmin Navionics+ U.S. Coastal & Great Lakes Mapping

Name: ECHOMAP™ UHD2 5" cv Chartplotters 54cv without Transducer; includes Garmin Navionics+ U.S. Coastal & Great Lakes Mapping
Brand: My Store
SKU: 1778474193
Price: 110.99 USD
Availability: InStock

$110.99 USD

~~$367.00 USD~~ $110.99 USD

Sale Sold out

ECHOMAP™ UHD2 5" cv Chartplotter helps you get to know the waters, & catch more fish with crystal-clear ClearVu Sonar, 5-inch display, preloaded maps, & more.

General
Dimension	7.4" x 4.8" x 2.4" (18.8 x 12.2 x 6.2 cm)
Weight	1.1 lbs (0.5 kg)
Water rating	IPX7
Display Type	WVGA, IPS
Display Size	4.3" x 2.6" (10.9 x 6.6 cm)
Display resolution	800 x 480 pixels
Mounting Options	Bail or flush
Input

Maps & Memory
Accepts Data Cards	1 microSD™ card; 32 GB maximum size
Waypoints	5,000
Track points	50,000
Tracks	50 saved tracks
Navigation Routes	100

Sensors
GPS
Galileo
Has built-in receiver
Receiver	5 Hz
Supports WAAS

Built-in Maps
Built-in Auto Guidance+	yes (downloadable via ActiveCaptain app)
Garmin Navionics+ Inland & Coastal	yes (see Additional)
Garmin Navionics+ (Coastal)	yes (see Additional)
Garmin Navionics+ (Inland)	yes (see Additional)
Tide tables	yes (see Additional)

Optional Map Support
BlueChart g3
BlueChart g3 Vision
LakeVü g3
LakeVü g3 Ultra
Garmin Navionics+™
Garmin Navionics Vision+™
TOPO 100K
Standard Mapping
Garmin Quickdraw Contours

Chartplotter Features
ActiveCaptain® compatible

Electrical Features
Power Input	9 to 18 Vdc
Typical current draw at 12 Vdc	1.0 A
Maximum current draw at 12 Vdc	1.5 A
Maximum power usage at 10 Vdc	18W

Sonar Features
Displays sonar
Power output	500 W
Traditional sonar (dual frequency/beam)	Built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP)
ClearVü	Built-in 260/455/800/1000/1200 kHz

Networking & Connections
4-pin transducer ports	1
Garmin Wi-Fi network (local connection)

Additional
Additional	Garmin Navionics+ (inland and coastal): 55cv Canada, 55cv Australia/New Zealand Garmin Navionics+ (coastal): 54cv U.S., 55cv U.K./Ireland Garmin Navionics+ (inland): 53cv U.S. lakes Tide tables: 53cv, 54cv, 55cv, 73cv, 74cv, 75cv
