EmpirBus™ SP8 and EmpirBus™ SP12 Switches SP12, Horizontal with Display

EmpirBus™ SP8 and EmpirBus™ SP12 Switches SP12, Horizontal with Display

$112.99 USD
$375.00 USD $112.99 USD
Sale Sold out

SP8

General
Manufacturer Grayhill, Inc.
Series 3K
Package bulk
Dimensions 4 x 2: (55.2 x 115.8 x 14.4 mm)
2 x 4: (104.7 x 62.8 x 21.7 mm)
Switch type snap dome
Number of keys 8
Matrix (columns x rows) 2 x 4
4 x 2
Illumination yes
Key type rubber overlay
Output type CAN-bus (J1939)
Legend color white
Key color black
Mounting type panel mount, front
Power supply 12/12 V
Connector 4-pin Dutch DT
Operating tempature -40° C ~ 85° C
Ingress protection IP67

SP12

General

Dimensions

 127.5 x 90.5 x 12.2 mm
Weight (unit only) 0.2 kg
Ambient temperature -20° C to +55° C
Enclosure water rating Ingress Protection - IP21
Communication CAN-bus NMEA 2000®
Regulation comp ABYC, RoHS, CE

Power Supply
Power consumption max/average 500 mA/0.25 mA
Supply voltage 9-32 Vdc

Connector
NMEA 2000 micro 5-pin M12 Male
