JL Audio® C1 Car Tweeter 1\" Component Tweeter

JL Audio® C1 Car Tweeter 1\" Component Tweeter

$25.99 USD
$84.99 USD $25.99 USD
Sale Sold out
C1 component tweeters with edge-driven aluminum domes, detailed treble frequencies, and versatile for various installation needs.

General
Warranty 1 year
Sizes 0.75"/1"
Continuous power handling (RMS) 0.75": 50 W
1": 60 W
Sensitivity (SPL @ 1 W/1 m) 0.75": 91 dB
1": 91.5 dB
Frequency response (+/- 3 dB) 0.75": 4 kHz-24 KHz
1": 3.6 kHz-22 KHz
Nominal impedance see Additional
Recommended amplifier power (RMS) 0.75": 20-50 W/Channel
1": 20-60 W/Channel
Cone material Mineral-filled polypropylene
Tweeter type Aluminum Dome
Tweeter size 0.75": 0.75" (19 mm)
1": 1" (25 mm)

Networking & Connections
Speaker connections Spade connectors

Tweeter Specifications
Flush mount fixture diameter 0.75": 1.67" (42 mm)
1": 1.97" (50 mm)
Surface mount fixture diameter 0.75": 1.71" (43 mm)
1": 2.01" (51 mm)
Flush mount mounting hole diameter 0.75": 1.46" (37 mm)
1": 1.75" (45 mm)
Flush mount mounting depth 0.40" (10 mm)
Flush mount tweeter frontal protrusion 0.75": 0.23" (6 mm)
1": 0.32" (8 mm)
Surface mount tweeter frontal protrusion 0.75": 0.76" (19 mm)
1": 0.87" (22 mm)

Crossover Specifications
Width 1.96" (50 mm)
Height 0.90" (23 mm)
Depth 1.34" (34 mm)

Additional
Additional

Nominal impedence: 0.75": 6 Ω; 1": 4 Ω
