Our E-Sub™ home subwoofer delivers game-changing bass with studio-grade signal processing. Available in 10- or 12-inch sizes and gloss black or ash finishes..
General
Warranty
3 years
Sizes
10"/12"
Physical dimensions (Height)
10": 14.24" (362 mm) 12": 16.23" (412 mm)
Physical dimensions (Width)
10": 13.5" (343 mm) 12": 15.5" (394 mm)
Physical dimensions (Depth)
10": 16.51" (419 mm) 12": 18.39" (467 mm)
Weight
10": 52.7 lbs (23.9 kg) 12": 73.5 lbs (33.3 kg)
Amplifier Power (RMS)
10": 1200 W short-term 12": 1500 W short-term
Frequency response (Anechoic)
10": 25-116 Hz (±1.5dB) 12": 22-118 Hz (±1.5dB)
Frequency response (Anechoic, -3dB)
10": 23 Hz/120 Hz 12": 21 Hz/120 Hz
Frequency response (Anechoic, -10dB)
10": 18 Hz/165 Hz 12": 17 Hz/153 Hz
Enclosure type
Sealed
Enclosure finish
Black ash or black gloss
Grille(s) included
Power modes
off, on or automatic (signal-sensing)
Signal Processing
Unbalanced input(s)
Stereo or mono (two RCA jacks)
Speaker/High-level inputs
Stereo or mono (removeable plug)
Input grounding
Isolated or grounded
Level control
Variable, from full mute to +15 dB over reference gain
Filter mode(s)
Low-pass
Filter slope(s)
24 dB/octave
Filter frequency range
25 Hz-130 Hz
Filter defeat function
Polarity
0 or 180º
Phase
Variable, 0-280º, referenced to 80 Hz
Line outputs
Stereo or mono (two RCA jacks), High-pass or Pass-through
