JL Audio Fathom™ v2 Powered Subwoofers 10\" with Gloss Black Finish (f110v2-GLOSS)

JL Audio Fathom™ v2 Powered Subwoofers 10\" with Gloss Black Finish (f110v2-GLOSS)

$105.99 USD
$350.00 USD $105.99 USD
Sale Sold out
Ideal for larger spaces, the Fathom® v2 home subwoofer with a powerful, 3,600 watt switching amplifier and digital automatic room optimization technology.

General
Warranty 3 years
Sizes 10"/12"/Dual 12"/13.5"
Physical dimensions (Height) 10": 15.64" (397 mm)
12": 18.5" (470 mm)
Dual 12": 31.96" (812 mm)
13.5": 19.25" (489 mm)
Physical dimensions (Width) 10": 12.92" (328 mm)
12": 15.0625" (384 mm)
Dual 12": 14.92" (379 mm)
13.5": 16.50" (419 mm)
Physical dimensions (Depth) 10": 17.27" (439 mm)
12": 17.75" (451 mm)
Dual 12": 20.39" (518 mm)
13.5": 19.25" (489 mm)
Weight

10": 69 lbs (31 kg)
12": 117 lbs (53 kg)
Dual 12": 224 lbs (102 kg)
13.5": 133 lbs (60 kg)
Light modes off, on or dim
Amplifier Power (RMS) 10": 1100 W short term
12": 1800 W short-term
Dual 12": 3600 W short-term
13.5": 3000 W short-term
Frequency response (Anechoic) 10": 27-111 Hz (±1.5 dB)
12": 21-119 Hz (±1.5 dB)
Dual 12": 20-97 Hz (±1.5 dB)
13.5": 20-86 Hz (±1.5 dB)
Frequency response (Anechoic, -3dB) 10": 25 Hz/120 Hz
12": 19 Hz/150 Hz
Dual 12": 19 Hz/110 Hz
13.5": 18 Hz/127 Hz
Frequency response (Anechoic, -10dB) 10": 19 Hz/155 Hz
12": 17 Hz/167 Hz
Dual 12": 15 Hz/157 Hz
13.5": 16 Hz/154 Hz
Enclosure type Sealed
Enclosure finish Black gloss
Grille(s) included
Power modes off, on or automatic (signal-sensing)

Signal Processing
Unbalanced input(s) Stereo or mono (two RCA jacks)
Balanced input(s) Stereo or mono (two female XLR jacks)
Input grounding Isolated or grounded
Input modes Master or slave
Level control Reference (fixed gain) or variable, from full mute to +15 dB over reference gain
Filter mode(s) Low-pass
Filter slope(s) 12/24 dB/octave
Filter frequency range 30 Hz-130 Hz
Filter defeat function
Polarity 0 or 180º
Phase Variable, 0-280º
Extreme Low Frequency (E.L.F.) trim Variable, -12 dB to +3 dB at 28 Hz
Output to slave Balanced (one male XLR jack)
Calibration mode Digital Automatic Room Optimization (D.A.R.O.), incudes laboratory-grade microphone

Parameters
Effective piston area (SD) 10": 60 in² (0.0387 m²)
12": 84 in² (0.0542 m²)
Dual 12": 168 in² (0.1084 m²)
13.5": 107.35 in² (0.0693 m²)
Effective displacement 10": 160 cu in (2.6 L)
12": 287 cu in (4.7 L)
Dual 12": 574 cu in (9.4 L)
13.5": 386 cu in (6.3 L)
